Product Description
Delivery scope and unit configuration
The parts included in the scope of delivery are inside the container and have to be removed first!
• To open the container → Installation.
 A
PondoClear Set 4000
Quantity
Submersion unit
1
Housing cover
1 x
2
Housing
1 x
3
Hose connector (1 × with O ring) and union nut
− For the connection of a 20 mm hose ∅ (6)
2 x
4
UVC clarifying unit
− A UVC lamp radiates and kills algae in the water
1 x
5
Pond pump
− First pumps the pond water into the UVC clarifying unit (4), then into the container (8)
1 x
6
20 mm hose ∅
− Connects the UVC clarifying unit (4) to the container (8)
1 x
Filter
7
Container cover
1 x
8
Container
− The delivery includes also the submersion unit, the hose (6) and a kit containing hose connectors (3), the infill
bend (13) and O rings
− Filter elements include foam filters (9/10) and bio balls (12)
1 x
9
− Coarse foam filter to mechanically clean and nitrify the water
1 x
10
Fine foam filter to mechanically clean and denitrify the water
1 x
11
Outlet matching the DN 50 HT tube or a 2" ∅ hose
1 x
12
Once colonised by bacteria, bio balls act as a filter element for biologically cleaning the water
15 x
13
Inlet bend
1 x
Function description
PondoClear Set 4000 is a filter system for mechanically and biologically cleaning of garden ponds. A pond pump
presses the water into various cleaning stages. Following this the water is returned into the garden pond.
Intended use
PondoClear Set 4000, referred to as "unit", may only be used as specified in the following:
• For cleaning garden ponds.
• Only operate with water at a water temperature of +4 °C to +35 °C.
• Operate in accordance with instructions.
The following restrictions apply to the unit:
• Do not use in swimming ponds.
• Never use the unit to convey fluids other than water.
• Never run the unit without water.
• Do not use for commercial or industrial purposes.
• Do not use in conjunction with chemicals, foodstuff, easily flammable or explosive substances.
Installation
The parts included in the scope of delivery are inside the container and have to be removed first!
Opening/ closing the container
How to proceed:
 B
Opening the container
• Carefully push the lugs located at the container side away from the detent tabs, then lift off the container lid.
Closing the container
• Place the container lid onto the container and carefully press down until the lugs engage over the detent tabs. (Not
shown.)
