- EN -
16
Fit filter
How to proceed:
C
1. Take kit, hose and submersion unit out of the container and place aside.
2. Insert the inlet bend through the inlet opening, then align with the container bottom.
3. Screw a hose connector from the kit on to the inlet bend at the outside of the container.
– The union nut of the hose connector must have an O ring. Insert, if necessary.
4. Close the container. (→ Installation)
Connect the submersion unit to the filter
How to proceed:
1. Screw a hose connector from the kit on to the outlet of the submersion unit.
2. Push the hose ends up to the hose connector stop of both units.
Installation and connection
WARNING
Possible death or severe injury from hazardous electrical voltage!
• Prior to reaching into the water, isolate (switch off and disconnect) all units/devices used in the water.
• Isolate the device (disconnect from the power supply) before carrying out any work on it.
How to proceed:
D, E
1. Place the submersion unit on level ground in the pond, and install the filter at the pond bank.
– Note the maximum submersion depth of the submersion unit.
– The filter can stand freely or can be buried up to half of its height as a maximum.
– Recommendation: The filter outlet points to the pond.
2. Return the water into the pond and ensure a sufficient hose gradient.
– A DN 50 HT tube system or 2" hoses can be used to return the water into the pond.
– On the unit side, the tube is pushed into the outlet or the 2" hose is fastened to the outlet using a hose clip.
3. Prepare the electrical connection.
– Route the connection tubes/hoses safely. (→ Safety information)
Operation
WARNING
Death or serious injuries from hazardous electrical voltage due to operation of this unit in a swimming pond.
• Never operate this unit in a swimming pond.
This is how to connect the power supply:
Switching on: Connect the unit to the mains. The unit switches on immediately.
Switching off: Disconnect the unit from the mains.
