10. SCHEMATICS AND PART NUMBERS
# CODE DESCRIPTION
1 PPN00037 CPP/CPPS ALUMINIUM CHASIS
2 PPN00039-1 CPP/CPPS FRONT COVER BLACK
3 PPN00060 CPP/CPPS FRONT STICKER
4 PPN00033 CPP/CPPS ACRYLIC FRONT
5 PPN00038 CPP/CPPS TOP CASE LID
6 PPN00022
CPP/CPPS TRANSFORMER 220VA
FOR 20G/HR MODEL
6 PPN00023-1
CPP/CPPS TRANSFORMER 340VA
FOR 30G/HR MODEL
6 PPN00024-1
CPP/CPPS/NEPTUNE
TRANSFORMER 440VA FOR
40G/HR MODEL
7 PPN00027 CPP/CPPS THERMOSTAT 100
o
C
8 PPN00040
CPP/CPPS HEAT SINK 90MM 40G/
HR MODEL
8 PPN00041
CPP/CPPS HEAT SINK 30MM UP
TO 30G/HR MODELS
9 PPN00025 CPP/CPPS SCR 65AMP FLAT BACK
10 PPN00028-1
OLD STYLE CPP/CPPS STANDARD
TIMER - BOSCHE MECHANICAL
10 PPS0051
OLD STYLE CPP/CPPS DIGITAL
TIMER
- FRONTIER QUARTZ
10 PPN00414
NEW STYLE CPP/CPPS STANDARD
TIMER - QUARTZ BOSCHE
MECHANICAL BATTERY B/UP
11 PPN00029
CPP/CPPS TIMER - BRACKET
HOUSING
12 PPN00026 CPP/CPPS ROCKER SWITCH
13 PPN00018
CPP/CPPS CIRCUIT BREAKER
3AMP 20&30G/HR MODELS
13 PPN00019
CPP/CPPS CIRCUIT BREAKER
5AMP 40G/HR MODEL
14 PPN00011 CPP/CPPS POWER CORD-AU
15 PPN00001
CPP/CPPS AC SOCKET SQUARE -
PUMP OUTLET
16 PPN00072 CPP PLASTIC RIVET WHITE
17 PPN00172
CPP PCB STANDARD WITH 4&6
PIN CONNECTOR
17 PPN00030 CPPS PCB REVERSE POLARITY
18 PPN00003 CPP METER STANDARD
18 PPN00002 CPPS METER REVERSE POLARITY
19 PPN00035
CPP/CPPS KNOB FOR
POTENTIOMETER
20 PPN00020
CPP/CPPS JUNCTION BOX
COMPLETE WITH COVER
21 PPN00160
CPP/CPPS JUNCTION BOX SCREW
- CENTRE SMALL
22 PPN00159
CPP/CPPS JUNCTION BOX SCREW
- OUTER LARGE
23 PPN00021
CPP/CPPS TERMINAL BLOCK 2
PIN
# CODE DESCRIPTION
24 PPN00034
CPP/CPPS CABLE GROMMET
6N-4
25 PPN00042 CPP/CPPS SCR BRIDGE LONG
26 PPN00043 CPP/CPPS SCR BRIDGE SHORT
27 PPEC2000PP-C
CPP POWER PACK COMPLETE
CPP20
27 PPEC3000PP-C
CPP POWER PACK COMPLETE
CPP30
27 PPEC4000PP-C
CPP POWER PACK COMPLETE
CPP40
27 PPRP2000PP-C
CPPS POWER PACK COMPLETE
CPPS20
27 PPRP3000PP-C
CPPS POWER PACK COMPLETE
CPPS30/CPPS30C
27 PPRP4000PP-C
CPPS POWER PACK COMPLETE
CPPS40/CPPS40C
27 PPRP5000COMM
CPPS POWER PACK COMPLETE
CPPS50C
57 PPN00670-1
CPP/CPPS PVC - REDUCING
BUSH 50X40MM
50 PPCC20EC
CPP20 REPLACEMENT CELL-5
PLATES 200MM, SOLID PLATE
CATHODE/ANODE
50 PPCC30EC
CPP30 REPLACEMENT CELL-7
PLATES 200MM, SOLID PLATE
CATHODE/ANODE
50 PPCC40EC
CPP40 REPLACEMENT CELL-9
PLATES 200MM, SOLID PLATE
CATHODE/ANODE
50 PPCC20RP
CPPS20 REPLACEMENT CELL-
5 PLATES 200MM, REVERSE
POLARITY
50 PPCC30RP
CPPS30 REPLACEMENT CELL-
7 PLATES 200MM, REVERSE
POLARITY
50 PPCC40RP
CPPS40 REPLACEMENT CELL-
9 PLATES 200MM, REVERSE
POLARITY
50 PPCC50RP-C
CPPS50 REPLACEMENT CELL-
13 PLATES 200MM, REVERSE
POLARITY
51 PPN00455
CPP/CPPS CELL CLIP 9 PLATE
BLUE CRYSTAL- NO ROD
52 PPSCCAP
CELL CAP (C/W CABLE, COVER,
CAP, BRASSWARE, WASHERS,
RESIN FILLED)
53 PPN00492 CELL CAP LOCKING RING
54 PPN00260
CPP/CPPS CELL SPACER (RODS
ONLY) BLACK
54 PPN00322
CPP/CPPS CELL SPACER (RODS
ONLY) BLUE
55 PPN00465
CPP/CPPS CRYSTAL CLEAR CELL
HOUSING - SMOKEY
56 OR925M CPP/CPPS O-RING CELL HOUSING
57 PPN00670-1
CPP/CPPS PVC - REDUCING
BUSH 50X40MM
