Before proceeding with installation of the device, it is very important to check the following points :
✓ The installation area should be dry and properly ventilated, (maximal ambient temperature of use :
35°C), protected from rain, splashes, water spray, and UV radiation. Ensure that the pH corrector product
container is kept in a place sufficiently remote from any electrical equipment and any other chemical
product.
Failure to comply with this instruction will lead to abnormal oxidation of the metallic parts which could
result in complete breakdown of the device.
✓ The assembly of the devices (according to the model) must be performed strictly in compliance with the
following layout diagram.
CONTROLLER BOX
✓ Choose a location that is easily accessible, close to the pump timer, far apart 2 meters maximum from
the chlorinator cell. Install the controller box vertically, far enough away from the pool to comply with
the regulatory distance in force in your country. Do not cover.
✓ Controller must be permanently connected to the pump timer by enslaving to the pump timer. Do
not use an extension cord. Do not plug the device into an electric power outlet. Beforehand, turn
off the differential circuit breaker. Ensure that the controller box well switches off when the filtration
pump stops.
Any contact between the controller box and the water can pull a risk of electrocution.
