Plumbing should be performed by a qualied Plumber or a pool industry service technician
where possible. It can however be done by the home handyman taking due care and
attention.
Warning: Do Not apply Priming Fluid to the Clear Cell Housing
All pipe work should be primed with priming uid before glue is applied, any high
pressure PVC glue will work, make sure both surfaces are well coated before mating the
connections as you will only have a few seconds before the glue bond will take.
Piping from the Filter to the Cell should enter the pipe connection closest to the cell head
as per the image below as this is where the water sense probe has been installed during
manufacture. NOTE: When plumbed from the other direction and used with variable
speed pumps having very low ow rates the water probe may not get covered with water
causing the chlorinator to display Priming Cell.
Plumbing
Salt Cell
Chlorinator
Filter
Pump
Optional
Return To
Pool Using
Outlet 1or 2
4
