Lights, Turn Signals and Windshield Wipers 131
Brief overview – Windshield wipers
This brief overview does not replace the informa-
tion provided in the chapter “Windshield wiper/
washer stalk”.
In particular, warnings are not replaced by this
brief overview.
Windshield wiper stalk Rain sensor rotary switch
What do I want to do? What do I have to do?
Automatic wiping at front
(rain sensor)
Press the stalk to detent position 1.
Rain sensor adjustment
Adjust rotary switch A in the stalk upwards (wipe more often) or downwards (wipe less often).
Wiping at front
Slow: Move the stalk to detent position 2.
Fast: Move the stalk to detent position 3.
Once: Briefly press stalk to position 4.
Spraying and wiping at front
Pull stalk to position 5 and hold.
Wiping at rear
Normal: Press stalk to position 6.
Once: Briefly move stalk to position 7.
Spraying and wiping at rear
Keep stalk pressed in position 7.
