Porter-Cable PCXB340SS - Interior Cutting Procedure

21
INTERIOR CUTTING (FIG. S)
1. Lay out the design on the workpiece (1).
Drill a 1/4 in. (6.4 mm) hole in the
workpiece.
2. Lift the blade tension knob (2) and remove
the blade (3). Refer to BLADE REMOVAL
AND INSTALLATION.
3. Place the workpiece on the table with the
workpiece hole (4) over the access hole in
the table (5).
4. Install the blade (3) through the hole in the
workpiece and tighten the blade tension
knob (2).
5. Follow the process 3 - 8 under the section
of FREEHAND CUTTING.
6. When nish the cutting, turn the scroll saw
OFF, remove the blade from the blade
holders and remove the workpiece from
the table.
Fig. S
4
3
2
5
1
