Porter-Cable PCXB115MS User Manual (English)

Questions and Answers:

E
Edward VazquezJul 31, 2025
What to do if Porter-Cable PCXB115MS blade binds, jams, or burns wood?
- C
  crystal48Jul 31, 2025
  If your Porter-Cable saw blade binds, jams, or burns wood, several factors could be at play. It could be due to a dull or warped blade, in which case you should replace or sharpen it. Ensure you are using the correct blade size; if not, replace it with a 10 in. (254 mm) diameter blade. Also, make sure the wood isn't moving during the cut; use a hold-down clamp to secure the workpiece to the table.
T
Tammy JordanAug 4, 2025
Why does my Porter-Cable PCXB115MS vibrate or shake?
- S
  Susan KentAug 4, 2025
  If your Porter-Cable saw vibrates or shakes, it could be due to a saw blade that is not round, damaged, or loose. Try replacing the blade. Another potential cause is a loose arbor bolt, which you should tighten.
N
nicolemccarthyAug 9, 2025
What to do if my Porter-Cable PCXB115MS motor does not start?
- R
  ryan18Aug 9, 2025
  If the motor of your Porter-Cable Saw doesn't start, the limit switch might have failed and needs replacement. Another cause could be worn brushes, which also need replacement. Also, check if a fuse is blown or a circuit breaker is tripped on your home panel, and verify that there is electrical power at the outlet.
R
Richard VegaAug 13, 2025
Why is the angle of cut not accurate on my Porter-Cable PCXB115MS Saw?
- P
  Pamela StricklandAug 13, 2025
  If the angle of cut isn't accurate or you cannot adjust the miter on your Porter-Cable Saw, check if the miter table is unlocked. Also, check for sawdust under the table and vacuum or blow it out, while wearing eye protection.
A
Amber BurnsAug 17, 2025
What to do if the brake does not stop the blade within 10 seconds on Porter-Cable PCXB115MS Saw?
- C
  Casey DavisAug 17, 2025
  If the brake on your Porter-Cable saw does not stop the blade within 10 seconds, the motor brushes may not be sealed or are lightly sticking; inspect, clean, or replace them. The motor brake could also be overheated from using a defective or wrong-size blade, or from rapid on/off cycling; use a recommended blade and allow the saw to cool down. A loose arbor bolt could also be the cause; retighten it. Also, check if the brushes are cracked or damaged and replace if needed.
B
browngregAug 21, 2025
Why does my Porter-Cable Saw cutting arm will not fully raise, or blade guard won’t fully close?
- B
  Brent MillerAug 21, 2025
  If the cutting arm on your Porter-Cable saw will not fully raise, or the blade guard won’t fully close, sawdust build-up could be the reason. Try cleaning and lubricating the moving parts.
B
Brandi WoodAug 26, 2025
Why does my Porter-Cable PCXB115MS Saw brush spark when switch released?
- R
  Robert WallaceAug 26, 2025
  If the brush sparks when the switch is released on your Porter-Cable Saw, it could be due to worn brushes. In this case, replace the brushes.

Porter-Cable PCXB115MS Specifications

General

Brand	Porter-Cable
Model	PCXB115MS
Category	Saw
Language	English

Summary

Safety Guidelines and Definitions

Warning Icons

Explains warning symbols used in the manual for safety.

Hazard Level Definitions

Defines DANGER, WARNING, CAUTION, NOTICE for hazard levels.

California Chemical Warning

Alerts to chemicals causing cancer or reproductive harm.

Respiratory Protection Warning

Warns about dust causing respiratory injury.

Power Tool Safety

General Safety Instructions

Provides essential safety rules before operating any power tool.

Specific Safety Rules

Details rules for safe operation, apparel, and work area.

Miter Saw Safety

Specific Safety Instructions

Lists crucial safety steps for miter saw operation.

Electrical Requirements and Safety

Power Supply and Circuit Protection

Details electrical requirements, circuit protection, and extension cords.

Motor Safety Protection

Covers motor safety, overload, and voltage requirements.

Tools Needed

For Blade and Adjustment

Lists required tools for blade work and adjustments.

Carton Contents

Unpacking and Checking

Details items included and unpacking procedures.

Unpacking Your Folding Miter Saw

Visual Inspection of Contents

Illustrates and identifies unpacked parts.

Know Your Folding Miter Saw

Identifying Saw Components

Illustrates and labels all parts of the miter saw.

Glossary of Terms

Woodworking and General Terms

Defines key terms related to miter saws and woodworking.

Assembly and Adjustments

Raising the Cutter Head

Step-by-step guide to raise the cutter head.

Setting Up the Saw Base

Instructions for placing the saw on a flat, stable surface.

Assembly and Adjustments

Locking and Folding the Cutting Head

Instructions for securing and folding the cutting head.

Installing Dust Bag and Hold-Down Clamp

Guides for installing dust bags and hold-down clamps.

Assembly and Adjustments

Saw Blade Wrench Storage

Location for storing the blade wrench.

Mounting the Miter Saw

Instructions for mounting the saw for stationary or portable use.

Assembly and Adjustments

Using the Support Base

Guidance on using the support base as an extension table.

Transporting the Saw Safely

Steps to safely lock and transport the folded saw.

Adjustment Instructions

Removing and Installing the Blade

Detailed steps for blade removal and installation.

Adjustment Instructions

Table Insert and Bevel Stop Adjustment

Procedures for table insert and bevel stop adjustments.

Adjustment Instructions

90° and 45° Bevel Adjustments

Steps for adjusting 90° and 45° bevel angles.

Miter Scale and Pointer Adjustment

Steps for adjusting miter scale and pointer.

Adjustment Instructions

Adjusting Fence Squareness

How to align the fence square to the blade.

Cutting Head Travel and Laser Guide Adjustment

Adjusting cutting depth and aligning the laser guide.

Adjustment Instructions

Laser Guide Safety and Adjustment

Warnings about laser use and guide alignment procedures.

Adjustment Instructions

Adjusting Laser Line Position

Fine-tuning vertical and horizontal laser line alignment.

Operation

Safety Instructions for Saw Operation

Critical safety rules for operating the saw.

Before Using the Miter Saw

Pre-operation checks and familiarization.

Operation

Work Area, Dress, and Inspection

Guidelines for work area, personal safety, and workpiece inspection.

Safe Cutting Practices

Rules for handling workpieces, avoiding over-reach, and freehand cuts.

Operation

Making a Basic Cut

Step-by-step guide for making a basic cut.

Operation

Before Leaving the Saw

Procedures for safely leaving the saw unattended.

Miter Cut Procedures

Steps for setting up and performing miter cuts.

Operation

Bevel and Compound Cut Procedures

Instructions for performing bevel and compound cuts.

Operation

Cutting Bowed Material and Workpiece Support

Guidance for cutting bowed material and supporting workpieces.

Support Base and Auxiliary Fence

Using the support base and adding an auxiliary wood fence.

Operation

Cutting Base Molding

Techniques for cutting base moldings.

Cutting Crown Molding

Techniques for cutting crown molding accurately.

Operation

Crown Molding Bevel/Miter Settings

Chart for precise bevel/miter settings for crown molding.

Crown Molding Chart

Miter and Bevel Angle Settings

Detailed chart for miter and bevel angles for molding.

Maintenance

Replacing Carbon Brushes

Procedure for replacing worn carbon brushes.

Lower Blade Guard and Sawdust Management

Maintenance of blade guard and cleaning sawdust.

Maintenance

Lubrication Guidelines

Guidance on necessary lubrication points for smooth operation.

Troubleshooting Guide

Motor Troubleshooting

Identifies common motor issues and corrective actions.

Troubleshooting Guide

Saw Operation Troubleshooting

Lists saw operation issues and suggested fixes.

Accessories and Attachments

Recommended Accessories and Safety

Advises on using compatible accessories and warnings.

Parts List

Parts List - Assembly A

Lists part numbers and descriptions for assembly A.

Parts List

Parts List - Assembly B

Lists part numbers and descriptions for assembly B.

Parts List

Schematic for Assembly A

Exploded view diagram for parts assembly A.

Parts List

Parts List & Schematic for Motor

Lists motor parts and provides a schematic.

Notes

General Notes

Contains miscellaneous notes and reminders.

Warranty

Three Year Limited Warranty

Details warranty coverage, free service, and money-back guarantee.
