Porter-Cable PCXB115MS - Table of Contents; Product Specifications

2
2017/04
TABLE OF CONTENTS
SECTION PAGE
PRODUCT SPECIFICATIONS..................................................................................... 2
SAFETY GUIDELINES - DEFINITIONS ..................................................................... 3
POWER TOOL SAFETY ............................................................................................. 4
MITER SAW SAFETY ................................................................................................. 6
ELECTRICAL REQUIREMENTS AND SAFETY ........................................................ 8
TOOLS NEEDED TO REMOVE OR INSTALL BLADE ............................................... 10
TOOLS NEEDED TO FOR ADJUSTMENT ................................................................ 10
CARTON CONTENTS ................................................................................................ 10
UNPACKING YOUR FOLDING MITER SAW ............................................................. 11
KNOW YOUR FOLDING MITER SAW ....................................................................... 12
GLOSSARY OF TERMS.............................................................................................. 13
ASSEMBLY AND ADJUSTMENTS ............................................................................. 15
OPERATION ............................................................................................................... 25
MAINTENANCE .......................................................................................................... 34
TROUBLESHOOTING GUIDE ................................................................................... 36
ACCESSORIES AND ATTACHMENTS ...................................................................... 38
PARTS LIST................................................................................................................. 39
WARRANTY................................................................................................................. 44
PRODUCT SPECIFICATIONS
Printed in China
WARNING
!
MOTOR CUTTING CAPACITY (Dimensional lumber)
Power Source .........
120 V AC, 60 Hz,
15 A
Cross Cut 0° x 0°.....................
2 x 6 in.
(50.8 x 152.4 mm)
Speed (No load) ......
4500 RPM Miter Cut 45° x 0° ....................
2 x 4 in.
(50.8 x 101.6 mm)
Electric Brake .......... Yes Bevel Cut 0° x 45° …......…......
2 x 6 in.
(50.8 x 152.4 mm)
Double Insulated ..... Yes Compound Cut 45° x 45° …....
2 x 4 in.
(50.8 x 101.6 mm)
BLADE
Crown Molding Nested ............ 4-1/4 in. (107.9 mm)
Diameter ................. 10 in. (254 mm)
Arbor ....................... 5/8 in. (16 mm) ROTATING TABLE
Miter Range .............................0-48° Left; 0-55° Right
Miter Detent Stops ..................
0°, 15°, 22.5°, 31.6°,
45° (R & L), 55° (R)
Bevel Range ........................... 0-47° Left
Bevel Positive Stops ...............
0°, 45° (L)
7RDYRLGHOHFWULFDOKD]DUGV¿UHKD]DUGVRUGDPDJHWRWKHPLWHUVDZXVHSURSHUFLUFXLW
SURWHFWLRQ7KLVPLWHUVDZLVZLUHGDWWKHIDFWRU\IRU9ROWRSHUDWLRQ,WPXVWEH
FRQQHFWHGWRD9ROW$PSHUHWLPHGHOD\IXVHRUFLUFXLWEUHDNHU7RDYRLGVKRFN
RU¿UHUHSODFHSRZHUFRUGLPPHGLDWHO\LILWLVZRUQFXWRUGDPDJHGLQDQ\ZD\%HIRUH
XVLQJ\RXUPLWHUVDZLWLVFULWLFDOWKDW\RXUHDGDQGXQGHUVWDQGWKHVHVDIHW\UXOHV
)DLOXUHWRIROORZWKHVHUXOHVFRXOGUHVXOWLQVHULRXVLQMXU\WR\RXRUGDPDJHWRWKH
PLWHUVDZ
