Porter-Cable PCXB115MS - Parts List; Parts List - Assembly A

39
10 IN. (254 MM) FOLDING COMPOUND MITER SAW
3$576/,67)25)2/',1*&203281'0,7(56$:$
PARTS LIST
I.D. No. Description Size Q’ty I.D. No. Description Size Q’ty
0831 SHAFT SLEEVE 1 0KDK CR. RE. PAN HD. SCREW M5*0.8-16 1
083Z CORD CLAMP 1 0KMS HEX. NUT M6*1.0 T=5 3
0CES COMPRESSION SPRING 1 0KQW LOCK NUT M5*0.8 T=5 1
0CPD CENTER BOLT 1 0KQX NUT M6*1.0 T=6 2
0D87 TORSION SPRING 1 0KR0 NUT
M12*1.75 T=12 1
0D9B ANCHOR BLOCK 1 0KR3 LOCK NUT M6*1.0 T=6 1
0DVJ BLADE WRENCH 1 0KR4 LOCK NUT M8*1.25 T=8 1
0HG1 COMPRESSION SPRING 1 0KUW TERMINAL 2
0J4E FLAT WASHER Ǘ 1 0LYH DUST GUARD 1
0J4M FLAT WASHER Ǘ 1 0S1S COLLAR 1
0J6A FLAT WASHER Ǘ 1 143G HEX. SOC. TRUSS HD. SCREW M6*1.0-16 2
0J7F FLAT WASHER 5/16*7/8-5/64 1 23NX CORD GUARD 1
0JB0 WAVE WASHER WW-8 2 271T FLAT WASHER Ǘ 1
0JE8 C-RING 1 2AH7 COMPRESSION SPRING 1
0JMP O-RING 1 2FUN COMPRESSION SPRING 1
0JPE HEX. HD. BOLT M6*1.0-20 2 2LWF CLEVIS PIN 1
0JPF HEX. HD. BOLT M6*1.0-25 1 2M0S LIMIT SWITCH 1
0JUJ HEX. SOC. HD. CAP BOLT M6*1.0-12 1 2N7W BRACING PLATE 1
0JUK HEX. SOC. HD. CAP BOLT M6*1.0-16 1 2PDE LASER WARNING LABEL 1
0JVD HEX. SOC. HD. CAP BOLT M5*0.8-35 1 2T9B ROCKER SWITCH ASS’Y 1
0JZF HEX. SOC. SET SCREW M6*1.0-10 3 2VEP SHAFT 1
0JZN ARBOR BOLT M8*1.25-20 1 2YR6 SPRING GUARD 1
0K2L HEX. SOC. HD. CAP SCREW M8*1.25-30 4 2ZPA DUST BAG ASS’Y 1
0K4T CR. RE. TRUSS HD. SCREW M5*0.8-20 2 31VX CR. RE. TRUSS HD. ROUND
NECK SCREW
M6*1.0-14 1
0K5D CR. RE. COUNT HD. SCREW M6*1.0-20 1 3544 LEAD WIRE ASS’Y 1
0K72 CR. RE. TRUSS HD. SCREW M5*0.8-12 2 35Q3 HEX. SOC. SET SCREW M6*1.0-8 1
0K7Z CR. RE. TRUSS HD. ROUND
NECK SCREW
M6*1.0-14 1 36Z9 TENSION PLATE 1
0KB7 CR. RE. PAN HD. TAPPING
SCREW
M4*18-16 8 3CK6 CONTROLLER ASS’Y 1
0KD7 CR. RE. PAN HD. SCREW M4*0.7-10 4 3FVK LASER COVER 1
0KDH CR. RE. PAN HD. SCREW M5*0.8-8 4 3FVL LASER COVER 1
0KDJ CR. RE. PAN HD. SCREW M5*0.8-12 1 3H9M PIVOT SHAFT 1
