Porter-Cable PCXB115MS - Parts List; Parts List - Assembly B

40
10 IN. (254 MM) FOLDING COMPOUND MITER SAW
3$576/,67)25)2/',1*&203281'0,7(56$:%
I.D. No. Description Size Q’ty I.D. No. Description Size Q’ty
3HHM CR. RE. COUNT HD. SCREW M4*0.7-8 4 3SPN MITER HANDLE 1
3HJ0
CR. RE. PAN HD. TAPPING SCREW M3*24-8 1 3SR0 ANGLE PEGULATOR 1
3LMY DISC SPRING WASHER Ǘ 1 3STM POWER CABLE 1
3MAY CR. RE. PAN HD. ROUND NECK
SCREW
M6*1.0-9 1 3STZ HOLD-DOWN CLAMP 1
3NY9 LASER ASS’Y 1 3SVQ SPECIAL BOLT 1
3NZ6 ARBOR COLLAR 2 3SZY TRIGGER 1
3PBU FENCE 1 3TUQ WARNING LABEL 1
3PC4 ANCHOR PLATE 1 3TUR CAUTION LABEL 1
3PCH LOCATION PIN 1 3TUS WARNING LABEL 1
3QJE LOCK PIN 2 3TUT WARNING LABEL 2
3QLP BUTTON SWITCH 1 3TUU LASER STICKER 1
3R49 TABLE INSERT 1 3TUV WARNING LABEL 1
3R7E BEVEL LOCK HANDLE 1 3TUZ TILTING SCALE 1
3RJS TRADEMARK LABEL 1 3TV0 SCALE 1
3S79 MOTOR ASS’Y 1 3TV1 LABEL 1
3S9G LEVER 1 3TV2 WARNING LABEL 1
3S9H MOTOR HANDLE (LEFT) 1 3TV3 WARNING LABEL 1
3S9J MOTOR HANDLE (RIGHT) 1 3U32 POSITIVE STOP LOCKING LEVER 1
3S9K NEEDLE POINTER 1 3U35 LOWER BLADE GUARD 1
3S9L TABLE 1 3U3B ANCHOR BLOCK 1
3S9N BASE 1 3U4D SUPPORT BASE 1
3S9P DETENT BLOCK 1 3U4G HEX. SOC. HD. CAP SCREW M6*1.0-30 2
3S9S SLIDE PLATE 1 3UHA BLADE 1
3S9Z CARRYING HANDLE 1 3UGY INSTRUCTION MANUAL 1
3SA0 CABLE SHIELD 1 3UTW CAUTION LABEL 1
3SA1 FOLLOWER PLATE 1 3UZ2 WARNING LABEL 1
3SAX CUTTER SHAFT GUARD 1 3UZN POWER CABLE ASS’Y 1
3SB9 LEAD WIRE ASS’Y 1 3UZP MAGIC TAPE 1
3SDU NEEDLE POINTER 1 3V0X WARNING LABEL 1
3SPD CR. RE. TRUSS HD. ROUND NECK
SCREW
M6*1.0-20 1 3V6S WARNING LABEL 1
