8- ENG
TYPICAL INSTALLATION
A Air flow
B Feeder line
C Drain leg
D Moisture trap with drain
E Non–lubricated supply line
F 1/4 turn valve
G Bypass
H Air dryer or aftercooler
J Line filter
K Drip tee with drain
L Air/water filter with petcock
M Regulator
N Lubricator
P Quick coupler
R Air hose to tool
T Flexible air line
U Lubricated supply line
I WARNING
I CAUTION
Risk of bursting, resulting in
injury. Never use Plastic pipe for
compressed air.
Risk of property damage. Never use lubricator
for paint spraying or similar applications.
