GAM Quick Installation Guide
Positron Access Solutions 7 Document 180-0212-001 R02
Figure 1: GAM-4-CR Local Power Input Connector
1.2.2 Ethernet (SFP+) Port
Figure 2: GAM SFP+ Connectors
The GAM has one (1) SFP+ ports that support any MSA-compliant SFP/SFP+
modules. (Fiber: 1G, 10G and Copper RJ-45: 100M, 1G).
Important note: When connecting the SFP+ port to a Passive Optical Network
(PON) fiber connection, please make sure to use an Optical Network Unit (ONU)
approved by the OLT vendor you are using.
