GAM Quick Installation Guide
Positron Access Solutions 13 Document 180-0212-001 R02
2.1 Step by Step Installation Procedure
Here is a step-by-step procedure to install the GAM-4-CRX and GAM-4-CX
outdoor unit.
Begin by connecting the AC-DC Power supply included as part of your GAM-4-CX.
You should skip this step if you are using a Reverse Power Fed GAM-4-CRX
unless you plan to temporarily power the GAM for a temporary 12Vdc power
source during the initial installation / activation of the unit.
Step 1: The 12Vdc connector is located at the
top right corner of the GAM enclosure. Pull on
the male power connector that ships pre-
installed in unit.
/
