POSX ION TP5 Pro - Specifications

5. Specications
Model
ION-TP5E-F ION-TP5F-F
CPU support
Intel Bay Trail CPU Celeron J1900
System memory
4GB / 8GB DDR3 SO-DIMM
Storage
32GB / 64GB pSSD
LCD touch panel
LCD size 14” TFT LCD (eDP)
Maximal resolution 1366 x 768
Brightness 200 nits
Touch screen type True Flat P.Cap Touch
Tilt angle 0°~90° ( w/o LCM and 2
nd
display)
Expansion I/O ports
USB port 4 x USB 3.0 Type-A / 1x USB2.0 USB, front side
COM port
3 x RJ-48
(COM1 0V/5/12V; COM2 0V/5V/12V; COM3 0V/5V/12V; default BIOS
setting 0V)
Cash drawer 1 x RJ-11 (12V/19V selection by jumper setting, default 19V)
LAN port 1 x RJ-45 ( 10/100/1000 Base T)
DC jack 4 pin w/ lock
Power
Power adapter 120W/19V
Control / Indicator
Power button 1
Printer feed button 1 NA
Printer LED Indicator 3 ( Paper, Error, Power ) NA
Peripherals
Built in printer
3” 6.7 inches/sec , Auto cutter,
Easy paper change, Out of paper
sensor, Paper roll dia. 3.15"
NA
MSR
3 Track MSR (USB)
Audio
Built in speaker 2W x 2 (Option)
Environment
Sealing IP54 (Display side)
EMC & Safety FCC, Class A, CE, LVD
ESD 4kV contact discharge, 8kV air discharge
Operating temperature
32°F ~ 95°F (0°C ~ 35°C)
Storage temperature
-4°F ~ 140°F (-20°C ~ 60°C )
Humidity 20% ~ 85% RH non condensing
Dimension (W x D x H)
LCD 90° tilt angle: 14.3” x 7.5” x 13.4” (363 x 189 x 340 mm )
Weight (N.W./G.W.)
11.0 lbs (5kg) / 13.2 lbs (6kg) 9.0 lbs (4.1kg) / 11.2 lbs (5.1kg)
OS support*
Windows 7; Windows 8.1; Windows 10; Linux
* This specication is subject to change without prior notice.
