Potensic D88 - Aircraft compass calibration; Step 1: Horizontal calibration; Step 2: Vertical calibration

!
Attention: To fly at GPS mode, please choose an open and wide space for the flight,
and make sure that the satellite number is over 7.
Step 2: Vertical calibration
Hold the aircraft with camera facing up, and rotate it 360 degrees along the central axis for
about 3 circles until the front and rear lights of the aircraft change from flashing to solid on,
the compass calibration is successful.
Two steps of compass calibration:
Step 1: Horizontal calibration
After successful aircraft initialization detection, the aircraft front and rear lights flash yellow
alternatively. Hold the aircraft horizontally and rotate it 360 degrees along the central axis for
about 3 circles. The aircraft front and rear light will change from flashing yellow alternatively
to flashing green alternatively when horizontal calibration is completed.
Aircraft compass calibration
1. Compass calibration should be performed after successful aircraft initialization detection.
2. Aircraft compass calibration should be done for every flight. That is to say, if changing new battery
or the battery is reinstalled, compass calibration should be done again.
Potenstic D88 User Manual
-25-
