To Next PageTo Next PageHow to fix Battery Trouble on Potter PFC-5000 Control Panel?
If your Potter Control Panel indicates a Battery Trouble, it could be due to low voltage (below 20.4V). Check that the batteries are present and in good condition. If the trouble persists, replace the batteries as soon as possible.
What to do if Potter Control Panel shows Ground Fault?
If your Potter Control Panel displays a Ground Fault, check for any external wiring touching the chassis or any other earth ground connection.
How to resolve Circuit Trouble on Potter PFC-5000?
To resolve Circuit Trouble on your Potter Control Panel, check for open wiring on the affected circuit loop. Also, ensure the circuit disconnect switch is in the ON or CLOSED position.
What causes Common Trouble on Potter Control Panel?
Common Trouble on a Potter Control Panel can be caused by an Initiating Circuit, Auxiliary power, or a 4-wire positive terminal shorting to the negative power supply. If a UDACT is in use, only common trouble is reported, as there are no unique UDACT reporting codes.
Why is my Potter Control Panel showing Charger Trouble?
If your Potter Control Panel is showing Charger Trouble, it indicates an internal battery charger fault. This fault will require factory repair.
General| Operating Temperature | 32°F to 120°F (0°C to 49°C) |
|---|---|
| Networking | Optional |
| Relative Humidity | 93% RH, non-condensing |
| Alarm Contacts | One Form C |
| Compatibility | Potter devices |
Overview of the manual and the PFC-5000 Fire Alarm Control Panel.
Key features of the PFC-5000 series panels.
Contact information for technical support.
Defines terms 'circuits' and 'zones' and their usage.
Explains Class B, Class A, Class Z, and Class Y wiring configurations.
Small enclosure panel with 2 Class B/1 Class A initiating circuits and 2 NAC circuits.
Small enclosure panel with 2 Class B/1 Class A initiating circuits and 2 NAC circuits.
Large enclosure panel with 4 Class B/2 Class A initiating circuits and 2 NAC circuits.
Large enclosure panel with factory-installed ZA-42 module.
Details on ZA-42, ARM-4, and ARM-8 modules.
Details on PR-5100 and UDACT-9100 modules.
Details on accessories like annunciators and battery cabinets.
Diagrams and dimensions for PFC-5002/PFC-5004 enclosure installation.
Diagrams and dimensions for PFC-5004E/PFC-5008 enclosure installation.
Diagram showing module mounting locations for PFC-5002/PFC-5004.
Diagram showing module mounting locations for PFC-5004E/PFC-5008.
Settings for the main module, including Class A/B selection and jumpers.
Class A/B selection and DIP switch configuration for ZA-42.
Relay control configuration and jumper settings for ARM-4/ARM-8.
Wiring diagram and terminal connections for UDACT-9100.
Terminal connections and wiring for PR-5100.
Techniques for dressing wires to prevent stress on connections.
Diagram of terminal connections for the main fire alarm module.
Continued diagram of terminal connections for the main fire alarm module.
Diagram of terminal connections for the ZA-42 Zone Adder Module.
Diagram of terminal connections for the ARM-4/ARM-8 Relay Module.
Wiring diagram for the UDACT-9100.
Terminal connections for the PR-5100 module.
Diagram illustrating power supply connections to the main board.
Wiring run data for initiating circuits based on wire gauge.
Wiring run data for NAC circuits based on load.
Pre-power-on checklist for system installation.
Steps for safely powering up the fire alarm control panel.
Table of common error messages and their descriptions.
Diagram showing the location of panel LEDs and controls.
Explains the function of various panel LEDs and the buzzer.
Functions of system reset, signal silence, fire drill, and aux. disconnect switches.
Functions of lamp test, buzzer silence, and circuit disconnect switches.
Describes how the panel handles alarm inputs and subsequent alarms.
Defines initiating and NAC circuits, and zones.
Describes non-verified and verified alarm circuits.
Describes water-flow alarm circuits.
Describes non-latching and latching supervisory circuits.
Describes silenceable and non-silenceable NAC circuits.
Describes visual NAC circuits.
Lists and describes evacuation codes like Continuous, Temporal, March, California.
DIP switch settings for configuring the main fire alarm board.
DIP switch settings for NAC Circuits #1 and #2.
DIP switch settings for audible/visual devices and annunciators.
DIP switch settings for signal silence and fire drill.
DIP switch settings for auxiliary disconnect and initiating circuits.
DIP switch settings for circuit style, AC power delay, signal code, zone disc, etc.
DIP switch settings for ZA-42 NAC Circuits #3 and #4.
DIP switch settings for ZA-42 audible/visual devices.
DIP switch settings for ZA-42 Initiating Circuits #5-8.
Unused DIP switch functions on ZA-42.
Notes for configuring the PFC-5000 main board.
Location of DIP switches on the ZA-42 module.
Key considerations when configuring the ZA-42 module.
Description of the RA8F Eight Zone Remote Annunciator.
General, electrical, and current specs for PFC-5002/PFC-5004.
General, electrical, and current specs for PFC-5004E/PFC-5008.
Specifications for the ZA-42 Zone Adder Module.
Specifications for ARM-4/ARM-8 Relay Modules.
Specifications for the PR-5100 module.
Specs for RTI-1, resistors, system type, and standards.
Table of power requirements and calculation of total current.
Calculation for required battery capacity and selection guidelines.
