Potterton Heatmax Combi HE Range User Manual

2.0 Troubleshooting
5
© Baxi Heating UK Ltd 2012
Is the Timer ON and calling for
heat ?
Ensure timer is set for Central
Heating ON (see any
instructions supplied with
timer).
Is the Room Thermostat (if
fitted) set high enough ?
15
10
5
20
25
15
10
5
20
25
Turn Room Thermostat to
maximum setting (typical
example shown).
If you don’t know what you need to do to
get the boiler to light, or need help with
the system and controls, contact your
installer as soon as possible.
YES
NO
CONTACT YOUR
INSTALLER OR
SERVICE ENGINEER.
YES
12
1
2
3
4
5
6
7
8
9
10
11
CH ON
CH OFF
Typical
examples of
external timer
NO

Potterton Heatmax Combi HE Range Specifications

General

Fuel Type	Natural Gas
Warranty	2 Years
ERP Rating	A
Type	Combi
Mounting	Wall-mounted
Operating Pressure	3 bar
Output Range	24kW to 30kW
Central Heating Max Power	24kW to 30kW
Hot Water Max Power	24kW to 30kW
