7
ELECTRICITY SUPPLY - Page 7
A 240 volts ~ 50Hz. single phase electricity supply fused at
3A must be provided in accordance with the latest edition of
the lEE wiring regulations and any other local regulations
that may apply. The current rating of the wiring to the boiler
must exceed 3 amperes and have a cross sectional area of
at least 0.75mm
2
in accordance with BS6500 1990 Table 16.
The method of connection to the electricity supply MUST
facilitate complete isolation of the appliance, preferably by
the use of a
fused three pin plug and unswitched, shuttered socket outlet,
both complying with the requirements of BS1363.
Alternatively, connection may be made via a fused double
pole isolator having a contact seperation of 3mm in all poles
and serving the appliance and system controls only.
TECHNICAL DATA - Page 7
Boiler Type B11Bs
Maximum Working Head 30.5m (l00ft)
Minimum Working Head (Fully pumped systems) 150mm (6in)
Minimum Circulating Head (Gravity systems) 1.2m (4ft)
Gas Supply Pressure 20 mbar
Maximum Flow Temperature 82°C
Electricity Supply 240v ~ 50Hz fused at 3A
Flow/Return Connection 28mm copper
Gas Supply Connection Rc, ½ (½ in BSP Female)
Power Consumption 20 watts
30 & 40 model 50 & 60 model
Water Content 1.8 litre 2.5 litre
0.4 gal 0.55 gal
Appliance Weight - installed 36.3 kg 44.0kg
80.0 lbs 97.0 lbs
Appliance Weight - lift 31.0kg 38.5 kg
BOILER INJECTOR GAS RATE INPUT OUTPUT BURNER PRESSURE
SIZE SIZE m3/h (ft3/h) Kw(Btu/h) kW(Btu/h) Mbar in wg
Min 0.76 (26.84) 8.20 (27978) 5.86 (20,000) 7.8 3.1
30 2.6mm 0.95 (33.54) 10.18 (34734) 7.33 (25,000) 11.8 4.7
Max 1.09 (38.49) 11.72 (40000) 8.79 (30,000) 15.7 6.3
Min 1.15 (40.51) 12.29 (41930) 8.79 (30,000) 9.5 3.8
40 3.1mm 1.33 (46.98) 14.25 (48620) 10.26 (35,000) 12.7 5.1
Max 1.46 (51.49) 15.62 (53295) 11.72 (40,000) 15.3 6.1
Min 1.47 (51.90) 15.74 (53700) 11.72 (40,000) 9.3 3.8
50 3.55mm 1.65 (58.36) 17.70 (60400) 13.19 (45,000) 11.6 4.7
Max 1.81 (64.00) 19.41 (66225) 14.7 (50,000) 14.2 5.7
Min 1.86 (65.68) 19.9 (68000) 14.7 (50,000) 10.8 4.3
60 3.8mm 2.01 (70.97) 21.60 (73800) 16.12 (55,000) 13.0 5.2
Max 2.17 (76.62) 23.3 (79500) 17.6 (60,000) 15.2 6.1
