OPERATOR'S MANUAL
MODEL:
PB195H46YT
LAWN TRACTOR
ALWAYS WEAR EYE PROTECTION DURING OPERATION
Visit our website: www.poulan-pro.com
WARNING:
Read this Man u al and follow all Warnings
and Safety Instructions. Fail ure to do so can
re sult in serious in ju ry.
IMPORTANT MANUAL Do Not Throw Away
Printed in U.S.A.
03076
417217 Rev. 1 01.08.08 SR

Table of Contents

Questions and Answers

  • I
    imartinezAug 21, 2025
    Why Poulan Pro PB195H46YT Lawn Mower engine will not turn over?
    • J
      Jeffrey DiazAug 21, 2025
      If the engine of your Poulan Pro Lawn Mower won't turn over, check these potential causes: * Ensure the brake pedal is depressed. Depress the brake pedal. * Make sure the attachment clutch is disengaged. Disengage the attachment clutch. * A weak or dead battery can prevent the engine from turning over. Recharge or replace the battery. * A blown fuse could be the issue. Replace the fuse. * Corroded battery terminals can also cause this problem. Clean the battery terminals. * Loose or damaged wiring might be the culprit. Check all wiring. * A faulty ignition switch, solenoid, or starter could be the cause. Check and replace if necessary. * Faulty operator presence switch(es) may also be the reason. Contact an authorized service center/department.
  • T
    Taylor WilcoxAug 26, 2025
    How to fix Poulan Pro PB195H46YT hard to start?
    • B
      Brad HuangAug 26, 2025
      If your Poulan Pro Lawn Mower is hard to start, consider these possibilities: * A dirty air filter can make it difficult to start. Clean or replace the air filter. * A bad spark plug might be the cause. Replace the spark plug. * A weak or dead battery could be the issue. Recharge or replace the battery. * A dirty fuel filter can also cause hard starting. Replace the fuel filter. * Stale or dirty fuel may be the problem. Empty the fuel tank and refill with fresh, clean gasoline. * Loose or damaged wiring can contribute to starting issues. Check all wiring. * Carburetor or engine valves may need adjustment, so you may need to check “To Adjust Carburetor” in the Service Adjustments section, or contact an authorized service center/department.
  • N
    nathanjenkinsAug 28, 2025
    Why Poulan Pro PB195H46YT Lawn Mower engine dies when shifted into reverse?
    • X
      xsimsAug 28, 2025
      If your Poulan Pro Lawn Mower engine dies when shifted into reverse, it may be because the Reverse Operation System (ROS) is not "ON" while the mower or other attachment is engaged. To resolve this, turn the ignition key to the ROS "ON" position. Refer to the Operation section for more details.
  • A
    Aaron AndersonAug 30, 2025
    What causes Poulan Pro PB195H46YT blades not to rotate?
    • T
      Tammy LucasAug 30, 2025
      If the mower blades on your Poulan Pro Lawn Mower won't rotate, it could be due to: * An obstruction in the clutch mechanism. Remove the obstruction. * A worn or damaged mower drive belt. Replace the mower drive belt. * A frozen idler pulley. Replace the idler pulley. * A frozen blade mandrel. Replace the blade mandrel.
  • A
    Ashley WalshSep 1, 2025
    What to do if Poulan Pro PB195H46YT Lawn Mower engine clicks but will not start?
    • J
      Jose CookSep 2, 2025
      If your Poulan Pro Lawn Mower engine clicks but doesn't start, here's what you can check: * The battery might be weak or dead. Recharge or replace the battery. * Corroded battery terminals can prevent starting. Clean the battery terminals. * Loose or damaged wiring could be the issue. Check all wiring. * A faulty solenoid or starter may be the cause. Check and replace the solenoid or starter.
  • A
    alejandraparkerSep 6, 2025
    How to troubleshoot uneven cut with Poulan Pro PB195H46YT Lawn Mower?
    • W
      William MccoySep 6, 2025
      An uneven cut with your Poulan Pro Lawn Mower can be due to: * A worn, bent, or loose blade. Replace the blade and tighten the blade bolt. * The mower deck not being level. Level the mower deck. * Buildup of grass, leaves, and trash under the mower. Clean the underside of the mower housing. * A bent blade mandrel. Replace the blade mandrel. * Clogged mower deck vent holes. Clean around mandrels to open vent holes.
  • W
    William CampbellSep 8, 2025
    What to do if Poulan Pro Lawn Mower battery will not charge?
    • W
      westryanSep 8, 2025
      If the battery on your Poulan Pro Lawn Mower won't charge, consider these possibilities: * Bad battery cells. Replace the battery. * Poor cable connections. Check and clean all connections. * A faulty regulator (if equipped). Replace the regulator. * A faulty alternator. Replace the alternator.
  • J
    James MooreSep 12, 2025
    What to do if Poulan Pro PB195H46YT Lawn Mower headlights are not working?
    • L
      Lauren ToddSep 12, 2025
      If the headlights on your Poulan Pro Lawn Mower are not working, check the following: * Ensure the light switch is turned “ON”. Turn the light switch “ON”. * The bulb(s) or lamp(s) may be burned out. Replace the bulb(s) or lamp(s). * A faulty light switch could be the issue. Check and replace the light switch. * Loose or damaged wiring can cause this problem. Check the wiring and connections. * A blown fuse might be the cause. Replace the fuse.
  • R
    Rachel LoveSep 13, 2025
    What causes loss of drive in Poulan Pro Lawn Mower?
    • V
      Veronica CurtisSep 13, 2025
      Loss of drive in your Poulan Pro Lawn Mower can be attributed to: * The freewheel control being in the “disengaged” position. Place the freewheel control in the “engaged” position. * A worn, damaged, or broken motion drive belt. Replace the motion drive belt. * Air trapped in the transmission during shipment or servicing. Purge the transmission.
  • M
    Michael SanchezSep 15, 2025
    Why Poulan Pro Lawn Mower engine continues to run when operator leaves seat?
    • C
      Christine ArnoldSep 15, 2025
      If the Poulan Pro Lawn Mower engine continues to run when the operator leaves the seat with the attachment clutch engaged, it indicates a faulty operator-safety presence control system. You should check the wiring, switches, and connections. If the issue persists, contact an authorized service center/department.

Summary

Safety Rules

General Operation

Instructions for general safe operation of the ride-on mower.

Slope Operation

Guidelines for safe operation on slopes, including precautions and techniques.

Children Safety

Precautions to prevent accidents involving children during operation.

Towing Safety

Service Safety

Safe Handling of Gasoline

Precautions for handling gasoline to prevent injury or property damage.

Assembly

Check Battery

Check Tire Pressure

Check Deck Levelness

Check Brake System

Operation

How to Use Your Tractor

Basic steps and procedures for operating the tractor safely.

Stopping Procedures

Instructions for stopping the mower blades, ground drive, and engine.

Moving Forward and Backward

Instructions for controlling the tractor's movement using drive pedals.

Adjust Gauge Wheels

Adjust Mower Cutting Height

Steps to set the desired cutting height for the mower.

Operating the Mower

Instructions for engaging and operating the mower deck.

Reverse Operation System (ROS)

How to use the Reverse Operation System for mowing in reverse.

Operating on Hills

Critical safety instructions for operating the tractor on slopes.

Before Starting the Engine

Essential checks and procedures before starting the engine.

Adding Gasoline

Proper procedures and safety precautions for fueling the tractor.

Starting the Engine

Step-by-step instructions for starting the tractor's engine.

Purge Transmission

Procedure to purge air from the automatic transmission.

Mowing Tips

Maintenance

Maintenance Schedule

A schedule outlining required maintenance tasks and intervals.

Before Each Use Checks

Essential checks to perform before operating the tractor.

Tractor Maintenance

Blade Care

Instructions for maintaining mower blades for optimal cutting.

Battery Care

Engine Maintenance

Procedures for maintaining the tractor's engine.

Service and Adjustments

Removing the Mower

Installing the Mower

Leveling the Mower

Procedures for adjusting the mower deck for level cutting.

Precision Side-to-Side Adjustment

Front-to-Back Adjustment

Replace Mower Drive Belt

Check Brake Operation

Replace Motion Drive Belt

Starting with a Weak Battery

Replacing the Battery

Engine Adjustments

Storage

Tractor Storage Preparation

Engine Storage Preparation

Procedures for preparing the engine and fuel system for storage.

Troubleshooting Points

Suggested Guide for Sighting Slopes

Poulan Pro PB195H46YT Specifications

General IconGeneral
BrandPoulan Pro
ModelPB195H46YT
CategoryLawn Mower
LanguageEnglish
