NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm
IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts.
Failure to do so could be hazardous, damage your snow thrower and void your warranty.
KEY PART
NO. NO. DESCRIPTION
REPAIR PARTS SNOW THROWER - MODEL PR271 (96192009102)
CONTROL PANEL / DISCHARGE CHUTE
KEY PART
NO. NO. DESCRIPTION
KEY PART
NO. NO. DESCRIPTION
1
2
2
05.19.002-A
1 587 53 57-01 HARNESS WIRE LIGHTS &
GRIPS
2 532 14 50-06 WIRE RETAINER
3
3
4
5
12
2
05.08.001-C
1 587 33 25-02 CABLE INTERLOCK
2 532 43 17-62 PIN GROOVED
3 812 00 00-14 E-RING
4 581 15 12-01 SPRING RETURN
5 532 19 79-91 CLIP CABLE BLACK
1
1
2
2
05.08.008-G
1 590 49 36-01 GRIP HANDLE HEATED
2 532 44 22-50 SCREW PAN HD TORX
1/4-20 X .75
