EPFLCenterofMicroNanoTechnology

CMi/WafermountingwithPOWATECP‐200andU‐200    Page3/6

5‐ Usethemanualrollingpadtonicely stickthetapetothewafer+theframe.Onesinglepass
isenough.Keeprollinguntilreachingtherollthetapewasinitiallystuckto.
Note:
ifthewaferishigherthantheframe,youmayneedtoadjustthetapestickingmanually.
 
6‐ Lowerthecuttingsystem.First,cutthetoppartofthetapebygentlypressingdownthe
bladeandgoingbackandforthonthetrack.Then,cutthewholeperiphery
oftheframe
usingthecircularcuttingblade.
 

7‐ Liftthecuttingsystembackup.Usingonehandtoholdtheframesteadyagainstthe
machine,usetheotheronetoremovethecutpartofthetape.

Rollallthewayup Adjustmanuallyifneeded
Cutthetoppart
Cuttheperiphery
Removetape
