Page 20 of 35 Reference: 708052-1 Issue date: 23-Jul-2014 Revision: B
4. Reset the overspeed brake.
(Turn knob counter clockwise)
TESTING OVERSPEED BRAKE TEST BUTTON
Twist the
↑UP control switch
and raise the platform
approximately 3 ft (.9m)
While twisting the ↓ DOWN
control switch, push the Over-
speed Brake Test Button
The hoist should stop quickly.
= Inspect
= Verify
=Perform process
Overspeed Brake has tripped.
To Next Page
