Powercraft 13
• Secure the guide at this distance with the socket head screws.
If the required distance between saw cut and side is 5 cm, set the indicator ‘5’ on the guide
exactly above the saw blade.
• Tighten the socket head screws again.
Cutting in
Fig. 9
If the starting position of the workpiece to be sawn is not the side, or if no hole has been drilled,
you must cut in. To do this, proceed as follows:
• Put the jigsaw on the rounded front of the bottom plate .
• Switch on the appliance and slowly lower the jigsaw until it touches the workpiece.
• Let the jigsaw cut into the workpiece gently without forcing it.
• When you are through the workpiece, take the jigsaw out of the hole.
• Place the appliance in the normal position in the sawn hole and continue the saw cut.
You can also cut in by first drilling a hole in the workpiece. To do this, use a bit that makes a hole
big enough for the saw blade. Now you can carry out the steps described under 'Sawing'.
During maintenance and cleaning always remove the mains plug from the socket.
Never use liquids when cleaning electrical parts of the jigsaw.
Maintain the jigsaw regularly to prevent unnecessary problems. This will ensure that your
appliance remains in optimum condition:
• Keep the bottom plate clean so that no inaccuracies occur during sawing.
• Keep the outside of the jigsaw clean so that all moving parts can move accurately and
without wear.
• Keep the ventilation slots of the motor clean so that these do not overheat.
• If the carbon brushes are worn the jigsaw will run noisily and unevenly. In the end the jigsaw
will no longer work. Have the carbon brushes replaced by an authorized service centre.
• Lubricate the saw blade guide regularly.
Cleaning
Regularly clean the machine housing with a soft cloth, preferably after each use. Keep the
ventilation slots free from dust and dirt.
If the dirt does not come off use a soft cloth moistened with soapy water. Never use solvents such
as petrol, alcohol, ammonia water, etc. These solvents may damage the plastic parts.
Faults
Should a fault occur, e.g. after wear of a part, please contact the service address on the warranty
card. In the back of this manual you find an exploded view showing the parts that can be ordered.
5. SERVICE & MAINTENANCE
GB
08 Powercraft
pack into power tools that have the switch on invites accidents.
b. Recharge only with the charger specified by the manufacturer. A charger that is suitable
for one type of battery pack may create a risk of fire when used with another battery pack.
c. Use power tools only with specifically designated battery packs. Use of any other battery
packs may create a risk of injury and fire.
d. When battery pack is not in use, keep it away from other metal objects like paper clips,
coins, keys, nails, screws, or other small metal objects that can make a connection from
one terminal to another. Shorting the battery terminals together may cause burns of a fire.
e. Under abusive conditions, liquid may be ejected from the battery; avoid contact. If
contact accidentally occurs, flush with water. If liquid contacts eyes, additionally seek
medical help. Liquid ejected from the battery may cause irritations or burns.
6) Service
a. Please use a qualified expert who uses original replacement parts to repair your power
tool. This will ensure proper functioning of the power tool.
b. Caution! The use of any accessories or additional tools other than those recommended in
this manual may lead to an increased risk of injury. Only use original replacement parts.
Special safety instructions
Before using the appliance:
• Check the following points:
• Does the voltage of the motor (230 V) correspond with the mains voltage?
• Are the feeder cable and plug in good condition: sturdy, without loose bits or damage?
• Has the saw blade lost any teeth and is it showing cracks or fractures?
• If so, replace the saw blade immediately.
• Is there enough room under the workpiece so that the saw blade does not come into
contact with the floor or work table as it moves up and down?
• Do the teeth of the saw blade point upwards?
• Always wear protective goggles when using the appliance.
• Maintain the appliance carefully.
• Do not use the appliance in a wet environment.
• Do not use the appliance for material which contains asbestos.
• Never leave the jigsaw unattended.
Additional safety rules for laser lights
The laser light/laser radiation used in this system is Class 2 with maximum output of 1 mW and
a wavelength of 400-700 nm. These lasers do not normally present an optical hazard, although
staring at the beam may cause flash blindness.
Caution – The use of optical instruments with this laser product will increase the
chance of eye damage.
Warning– Do not stare directly at the laser beam. A hazard may exist if you deliberately stare
into the beam, please observe all safety rules as follows;
• The laser shall be used and maintained in accordance with the manufacturer’s
instructions.
• Never aim the beam at any person or an object other than the work piece.
GB
