POWER ELECTRONICS
SD700 – PROFIBUS
INTRODUCTION
13
E
N
G
L
I
S
H
1. INTRODUCTION
1.1. Description of Profibus Board
The Profibus Board for SD700 allows integrating these drives of Power
Electronics into Profibus networks easily and comfortably.
Its useful design will allow you to know the operating status of the
board all the time.
Figure 1.1 Description for Profibus Board
1
2
3
1. Profibus network connector
2. Connector for drive
3. Status leds
