o BIT 6 = Err. SYS SCEN. MODBUS WRITE
This BIT is set if some errors occur when trying to write in the
internal system defined MODBUS address.
o BIT 7 = Err. SYS SCEN. MODBUS READ
This BIT is set if some error occurs when trying to read from the
internal system defined MODBUS address (like the Profibus slave
address)
4.1.5. Scenarios Status
Byte 8
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
Write Scenario 2 Status
Write Scenario 1 Status
Byte 9
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
Write Scenario 4 Status
Write Scenario 3 Status
Byte 10
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
Write Scenario 6 Status
Write Scenario 5 Status
Byte 11
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
Write Scenario 8 Status
Write Scenario 7 Status
Byte 12
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
Write Scenario 10 Status
Write Scenario 9 Status
