Power Measurement ION 8000 Series - Meter Labels

7
Meter Labels
Framework File Naming Convention
CTR
PKh
WATT
TEST
MODE
SHIFT
UP
SHIFT
DOWN
ALT/
ENTER
Mult by
:1
:5
TYPE 8500
Multifunction Watthour/Varhour Meter
DEMAND
RESET
TA
CA
Freq
CL
Kt
V~
W
FM
VAR
VTR
4WY
120
-277
2.5
0.2
1.8
60
9S
20
Voltage
transformer ratio
Current
transformer ratio
Primary watthour
constant
Transformer factor
(VTR x CTR)
Form factor
diagram
Serial number and
ANSI bar code area
Wiring
configuration
Form factor
Class designation
Test constant
(LED pulse rate)
Class accuracy
Voltage input
rating
Tes t a mp s
8X00_VXX_FAC_C2A‐36S_V1.X.X.X.X.fwn
Meter type: 83/84/8500
Firmware version
Factory default framework Meter form factor (36S, 35S, 9S...)
Framework version
ANSI Class 2 (IEC 1A). ANSI Class 20 (IEC 5A) if blank
