LEGREST
Your legrest is designed to be removed and replaced the same as
your footrest. However, it is advisable to remove and replace your
legrest while the footrest is in a down position. Lifting on the
footplate raises the legrest and it will automatically lock at the
raised position.
1
2
Number Description Quantity
1 Legrest Release
Assembly
2
2 Legrest Hanger 2
• Pulling back on the black coated
tab (1) on the elevating locking
device lowers the legrest.
• Pull up on (2) to raise the legrest
