ANTI-TIPPERS
Your Anti-Tippers are used to prevent your chair from tipping over
while in tilt. These can be removed. However, they must never be removed
when using chair.
To remove Anti-Tippers:
Loosen the bolt (1) and remove it from the frame
To adjust the Anti-Tipper height:
Pull on (4) while moving (2) to your desired position release (4) to
lock into place
*Please adjust your Anti-Tippers to a safe height (maximum 2” from the
ground). Whenever the seat height is adjusted by wheels the Anti-Tipper
height must be adjusted as well.
# Description Quantity
1 Bolt 1
2 Height Extension
Tube
1
3 Housing 1
4 Locking Pin 1
5 Anti-Tipper Wheel 1
4
1
2
3
5
