TIRES
The standard tires on your chair are solid, maintenance free urethane. These tires
are reliable, long lasting and provide a very comfortable ride. However, if your
chair is equipped with pneumatic tires, they must be regularly checked for wear
and proper inflation. Air pressure should not exceed 40psi. Remember heated air
expands, and a wheel with 40psi in warm weather will greatly increase outdoors
or in the trunk of a car in the hot sun.
WHEEL LOCKS
The position of the wheel lock is pre-set at the factory to provide you with the
safest performance. However, with tire and brake shoe (3) wear, they may have
to be occasionally adjusted to ensure safety.
To adjust, loosen the bracket bolts (5) and slide brake assembly (2) towards
wheel. Ensure that the brake holds securely but does not require too much effort
to be applied. Then tighten the bracket bolt, securing assembly at the appropriate
position. Although lubrication is not necessary, a light application can enhance
performance.
Number Description Quantity
1 Tires 2
2 Bracket Bolt 2
3 Brake Shoe 2
4 Brake Handle 2
5 Bracket Bolt 4
6 Bracket Bolt Key 2
5
6
2
4
3
1
