KAYAK MOUNT
NOTE: If unable to mount using the adjustable bracket provided
or the available Transom Clamp, contact JL Marine System’s Inc.
or your kayak dealer for mounting options.
Attaching / Removing Driver Unit
Install the MICRO Driver Unit into its mount as shown.
Next, push the release clamp bolt
through and thread the adjustable nut
(K) on tight by turning clockwise and
lock quick release clamp into position.
K
L
L
J
