Power smart 196cc User Manual

17
ADDING A FUEL STABILIZER TO EXTEND FUEL STORAGE LIFE
When adding a fuel stabilizer, fill the fuel tank with fresh gasoline. If only partially filled, air
in the tank will promote fuel deterioration during storage. If you keep a container of
gasoline for refueling, be sure that it contains only fresh gasoline.
1. Add fuel stabilizer following the manufacturer’s instructions.
2. After adding a fuel stabilizer, run the engine outdoors for 10 minutes to be sure that
treated gasoline has replaced the untreated gasoline in the carburetor.
3. Stop the engine.
4. Move the fuel valve to the OFF position.
If engine has a KNOB FUEL SWITCH, then follow step 1 2 3 and 4, If
engine not has a KNOB FUEL SWITCH, then follow step 1 2 3.
DRAINING THE FUEL TANK AND CARBURETOR
1. Place an approved gasoline container below the carburetor, and use a funnel to avoid
spilling fuel.
2. Remove the carburetor drain bolt, and then pull out the fuel tube.
3. After all the fuel has drain into the container, reinstall the drain bolt and fuel tube.
Tighten them securely.
Storage Precautions
1. Change the engine oil.
2. Remove the spark plugs.
3. Pour a tablespoon (5-10 cc) of clean engine oil into the cylinder.
4. Pull the starter rope several times to distribute the oil in the cylinder.
5. Reinstall the spark plugs.

Power smart 196cc Specifications

General

Type	Single cylinder, 4-Stroke, Forced Air Cooling, OHV
Bore×Stroke(mm)	68×54
Displacement(cc)	196
Net power(kW/3600rpm)	4.1
Net torque (N·m/rpm)	12.4/2500
Fuel consumption (g/kW·h)	≤395
Speed Fluctuating Ratio	≤10%
Compression Ratio	8.5:1
P.T.O shaft rotation	Anti-clockwise(from P.T.O. side)
Oil capacity(L)	0.6
Noise(≤)	70dBA
Lubricating mode	Splash
Starting Mode	Recoil start / Electric starting
Valve Clearance	input valve：0.10~0.15mm, output valve：0.15~0.20mm
Spark plug clearance	0.7~0.8mm
Igniting Mode	Transistorized magneto Ignition
Air cleaner	No filter

Weight and Dimensions

Dimension(L×W×H) (mm)	382×354×276
