Power smart 196cc User Manual

19
8． TROUBLESHOOTING
ENGINE
WILL NOT
START
Possible Cause Correction
1. Electric starting:
check battery
Battery discharged. Recharge battery.
2. Check control
positions
Choke OPEN.
Move lever to CLOSE
unless engine is warm.
Engine switch pull out. Put engine switch in.
3. Check fuel.
Out of fuel. Refuel
Bad fuel; engine stored
without treating or draining
gasoline, or refueled with
bad gasoline.
Drain fuel tank and
carburetor. Refuel with
fresh gasoline.
4. Remove and
inspect spark plugs.
Spark plugs faulty, fouled,
or improperly gapped.
Gap, or replace spark
plugs.
Spark plugs wet with fuel
(flooded engine).
Dry and reinstall spark
plugs.
5. Take engine to an
authorized
servicing dealer,
or refer to
manual.
Fuel filter clogged,
carburetor malfunction,
ignition malfunction, valve
stuck, etc.
Replace or repair faulty
components as necessary.
ENGINE
LACKS
POWER
Possible Cause
Correction
1. Check fuel.
Out of fuel. Refuel
Bad fuel; engine stored
without treating or draining
gasoline, or refueled with
bad gasoline.
Drain fuel tank and
carburetor. Refuel with
fresh gasoline.
2. Take engine to an
authorized
servicing dealer,
or refer to
manual.
Fuel filter clogged,
carburetor malfunction,
ignition malfunction, valve
stuck, etc.
Replace or repair faulty
components as necessary.

Power smart 196cc Specifications

General

Type	Single cylinder, 4-Stroke, Forced Air Cooling, OHV
Bore×Stroke(mm)	68×54
Displacement(cc)	196
Net power(kW/3600rpm)	4.1
Net torque (N·m/rpm)	12.4/2500
Fuel consumption (g/kW·h)	≤395
Speed Fluctuating Ratio	≤10%
Compression Ratio	8.5:1
P.T.O shaft rotation	Anti-clockwise(from P.T.O. side)
Oil capacity(L)	0.6
Noise(≤)	70dBA
Lubricating mode	Splash
Starting Mode	Recoil start / Electric starting
Valve Clearance	input valve：0.10~0.15mm, output valve：0.15~0.20mm
Spark plug clearance	0.7~0.8mm
Igniting Mode	Transistorized magneto Ignition
Air cleaner	No filter

Weight and Dimensions

Dimension(L×W×H) (mm)	382×354×276
