Power smart 196cc User Manual

Keep this owner's manual handy, so you can refer to it at any time.
This owner's manual is considered a permanent part of the engine and should remain with
the engine if resold.
The information and specifications included in this publication were in effect at the time of
approval for printing.
Only the D Type is equipped for both electric and manual starting.
READ THIS OWNER’S MANUAL CAREFULLY. Pay special attention to these symbols
and any instructions that follow:
Indicates serious injury or death will result if instructions are not
followed.
Indicates a strong possibility that serious injury or death could
result if instructions are not followed.
Indicates a possibility that minor injury or an result if instructions
are not followed.
Indicates that equipment or property damage can result if
instructions are not followed.
NOTE: Gives helpful information.
If a problem should arise, or if you have any questions about your engine, consult your
engine dealer.

Power smart 196cc Specifications

General

Type	Single cylinder, 4-Stroke, Forced Air Cooling, OHV
Bore×Stroke(mm)	68×54
Displacement(cc)	196
Net power(kW/3600rpm)	4.1
Net torque (N·m/rpm)	12.4/2500
Fuel consumption (g/kW·h)	≤395
Speed Fluctuating Ratio	≤10%
Compression Ratio	8.5:1
P.T.O shaft rotation	Anti-clockwise(from P.T.O. side)
Oil capacity(L)	0.6
Noise(≤)	70dBA
Lubricating mode	Splash
Starting Mode	Recoil start / Electric starting
Valve Clearance	input valve：0.10~0.15mm, output valve：0.15~0.20mm
Spark plug clearance	0.7~0.8mm
Igniting Mode	Transistorized magneto Ignition
Air cleaner	No filter

Weight and Dimensions

Dimension(L×W×H) (mm)	382×354×276
