MAINTENANCE
WARNING: In order to avoid personal injury and the risk of fire and electric shock, always
pull out the mains power plug before adjusting, inspecting, or cleaning the power tool.
WARNING: When servicing, use only identical replacement parts. Use of any other parts
could create a hazard or cause product damage.
Replacing the power cable
WARNING: If the power cable for this equipment is damaged, it must be replaced by the
manufacturer or its after-sales service or similarly trained personnel to avoid danger.
Replace, sharp and change blades(Fig.13-15)
The blades on the blade plate are replaceable. If you have to replace any blade, you must only use
genuine blades to ensure that they meet the relevant quality and safety criteria.
WARNING: For safety reasons we recommend that you have all sharpening and blade
replacement work carried out by a specialist workshop.
WARNING:Always wear heavy duty working gloves.
Swing open the loading funnel by opening the release screw (Fig.13) and remove it.
Undo the six Philips screws and remove the cover plate (Fig.14) .
Secure the rotary disk so that it cannot rotate (for example by jamming it with a screwdriver, see
Fig.15)
Undo the four blade screws and remove the blades.
Each of the blades can be turned once as they are ground sharp on both ends. Then they must be
replaced by new blades.
To assemble, proceed in reverse order.
