OPERATING INSTRUCTION
WARNING: Be sure to read the fuel information in the safety rules before you begin. If you
do not understand the safety rules, do not attempt to fuel your unit.
Check Points Before Operation
● Check for loose bolts, nuts and fittings.
● Check the air cleaner for dirt. Clean the air filter of all dirt, etc. before operation.
● Check to be sure that protector is securely in place.
● Check to be sure that fuel is not leaking.
● Check to be sure that blade is not cracked.
Starting Cold Engine
1. Set unit on a flat surface.
2. Slowly press the primer bulb(14) about 5 times, then move choke lever(13) to the START position.
3. Move the START/STOP Switch(3) to "START" position.
4. Catch the machine handle, Squeeze and hold the throttle trigger(10) locked(press the button beside
the START/STOP Switch(3) together or we can not lock it successfully).
5. Pull recoil starter handle(1) sharply 1~6 times until engine starts. Slowly move choke lever to the
RUN position.
6. Allow engine to warm up for a few minutes before using.
Starting Warm Engine
1. The choke lever(13) to the "RUN"position .
2. Squeeze and hold trigger(3).
3. Pull recoil starter handle(1) until engine starts.
NOTE: If the starter rope is pulled repeatedly with the choke on, it may flood the engine and make
starting difficult. If you have flooded the engine, remove the spark plug and gently pull the handle on
the starter rope to eliminate any excess fuel; then dry the spark plug electrodes and replace it on the
engine.
Stopping The Engine
1. Release the throttle trigger and allow the engine to run idle for a few seconds.
2. Move START/STOP switch(3) to STOP position.
Operating
When operating the unit, you should clip the shoulder strap onto the clamp, check for the following:
● Wear hearing protection, eye protection, head protection and heavy clothing.
● Extend your left arm and hold handlebar grip with your left hand.
To Next Page
