** NOTE: Item #3 MAIN STATOR ASSEMBLY is a one-piece unit. The Stator cannot be separated from the
Generator’s outer housing.
8 – 10 - 12KW “C” or “M” BRUSH TYPE GENERATOR ASSEMBLY
DESCRIPTION
1. COVER SCREEN
2. BEARING PLATE
3. STATOR ASSEMBLY **
4. ROTOR BEARING
5. BRUSH SET
6. ROTOR ASSEMBLY
4
