25
Digital display: 100% Battery pack fully charged
No digital display lights
Battery is flat and needs to be
charged
Charge the battery pack before operating when it is at medium or
low battery charging level.
Red LED
Green LED
Red LED
Green LED
i. Connect the battery pack to the battery charger.
ii. Insert the mains plug into the socket. The green charging
status LED light will flash. Once the battery pack is completely
charged, the green charging status LED will remain still,
indicating that the charging process is complete.
iii. Disconnect the charger from the mains and remove the
battery pack from the charger.
iv. Attach the battery pack back to the product.
Charging status LEDs
Red LED turns on Charger ready
Green LED flashes Battery pack charging
Green LED continuously lit (still) Battery pack fully charged
Red and green LEDs flashing Battery pack defect
Red and green LEDs
continuously lit
Battery pack too cold or warm
Button
Digital Display Lights
