Page #26 background image
26
PowerBox-Systems − World Leaders in RC Power Supply Systems
11. SPECIFICATION
Operating voltage: 4.0 Volt to 9.0 Volt
Power supply: 2 x two-cell LiPo/LiIon battery, 7.4 Volt
2 x five-cell NiCd / NiMH batteries,
2 x two-cell LiFePo batteries (A123)
Current drain: switched on - approx. 125 mA
switched off - approx. 33
µA
Dropout voltage: approx. 0.25 V
Max. receiver and
servo current: 2 x 10 A (stabilised) according to cooling
Peak 2 x 20 A
Servo signal resolution: 0.5
µs
Signal repeat rate: 9 ms, 12 ms, 15 ms, 18 ms, 21 ms
(frame rate)
Screen: OLED 128 x 64 pixels, graphic
Servo sockets: Professional: 12 sockets, 8 channels
Competition: 18 sockets, 12 channels
Cockpit: 21 sockets, 11 channels
Temperature range: -30°C to +75°C
Weight: 115 g
SensorSwitch: 15 g
EMV approval: EN 55014-1:2006
CE approval: 2004/108/EG
WEEE Reg. No.: DE 639 766 11
This battery backer fulfils the EMV protective requirements, EN
55014-1:2006 with certificate dated 10 February 2009. EMC approval
2004/108/EG.
The unit must not be connected to a mains PSU!
The PowerBox Cockpit, Competition and Professional is intended exclusi-
vely for use in modelling applications. It is prohibited to use it for any purpo-
se other than in radio-controlled models.
