Climate Control Duplex
Basic Alternator Package
All Powerex duplex air compressors may be ordered with a
simplified line voltage basic alternator package. The basic
alternator package consists of an alternating coil and two
magnetic motor starters. Motor starters are selected and
wired for intended input voltage and are furnished with
properly sized overload heaters.
Automatic Tank Drain
Powerex air compressors may be ordered with a manual
or electric type automatic tank drain. A manual drain
attachment is furnished with each unit.
Vibration Dampening Pads
Waffle type design vibration pads are provided as standard
equipment.
Operation
Factory calibrated DPST pressure switches provide lead and lag
settings. When using an alternator-starter package, the lead
switch energizes the alternator and the alternator activates
the compressor that was on standby during the previous cycle.
If the demand exceeds the capacity of one compressor, the lag
switch will cause both compressors to run simultaneously. Upon
failure of either compressor, the lag switch will continue to
activate the workable compressor.
Single-phase motors (3/4 HP & 1 HP) have built-in overload
protection with manual reset. Three-phase motors require
a magnetic starter and three overload heaters. Heaters are
included with three-phase compressors that have a factory
mounted alternator.
NOTE: All pump models operate turning clockwise opposite
the motor shaft / pump flywheel / belt guard side of the unit.
Improper rotation will cause oil to spray out of the breather
vent opening.
Safety Guidelines
This manual contains information that is very important
to know and understand. This information is provided for
SAFETY and to PREVENT EQUIPMENT PROBLEMS. To help
recognize this information, observe the following symbols.
Danger indicates an imminently
hazardous situation which, if
not avoided, WILL result in death or serious injury.
Warning indicates a potentially
hazardous situation which, if
not avoided, COULD result in death or serious injury.
Caution indicates a potentially
minor or moderate injury.
Notice indicates important
information, that if not
followed, may cause damage to equipment.
NOTE: Information that requires special attention.
CALIFORNIA PROPOSITION 65
This product or its power cord
may contain chemicals known
to the State of California to cause cancer and birth defects or
other reproductive harm. Wash hands after handling.
Installation
MOUNTED AND CONNECTED OPTIONS
Deluxe Alternator Package
All Powerex Duplex air compressors may be ordered with
an optional deluxe alternator package consisting of two
magnetic motor starts with thermal overloads, an alternating
coil, a 120 VAC control transformer and a three-position
selector switch. The three-position switch allows for
automatic alternation or only running one unit at a time. This
will allow for service on one unit while other unit is running.
Performance Specifications
Base Model
Motor Rating
Compressor RPM
Compressor Capacity ACFM @ 80 psig
HP RPM 100% Runtime 50% Runtime 33% Runtime
AD-107 0.75 1725 980 2.1 1.07 0.71
AD-007 0.75 1725 980 2.1 1.07 0.71
AD-110 1.0 1725 1120 3.5 1.74 1.15
AD-010 1.0 1750 1120 3.5 1.74 1.15
AD-015 1.5 1760 860 4.6 2.3 1.5
AD-020 2.0 1755 1250 6.9 3.4 2.3
AD-030 3.0 1725 1050 10.3 5.2 3.4
AD-050 5.0 1750 1150 19.0 9.5 6.3
AD-075 7.5 1750 950 28.6 14.3 9.5
AD-100 10.0 1765 880 37.8 18.9 12.5
NOTE: 0.75 HP pumps must be used under altitudes of 5000 feet.
Above 5000 feet, 1 HP pumps must be used.
