Powerex ad series User Manual

7
Climate Control Duplex
Quantity Shipping Code
Item Description Required Weight Number
G BELT:
Motor HP Size
3/4 A-42 2 0.3 A-010-6006AP
1 A-43 2 0.3 A-010-6006AP
1-1/2 AX-46 2 0.3 A-015-6006AP
2 A-59 2 0.4 A-020-6006AP
3 B-62 2 0.4 A-030-6006AP
5 B-67 2 1.6 A-050-6006AP
7-1/2 B-69 4 2.0 A-075-6036AP
7-1/2 B-75 4 2.0 A-075-6056AP
10 A-80 4 2.4 A-100-6006AP
H MOTOR PULLEY:
Motor HP Type
3/4 1A-5.7 inch P.D., 5/8 inch Bore 2 3.9 A-007-6007AP
1 (1Ø) 1A-5.7 inch P.D., 5/8 inch Bore 2 3.2 A-110-6007AP
1 (3Ø) 1A-6.0 inch P.D., 7/8 inch Bore 2 3.2 A-010-6007AP
1-1/2 1A-5.5 inch P.D., 7/8 inch Bore 2 5.6 A-015-6007AP
2 1BK-8.0 inch P.D., 7/8 inch Bore 2 5.2 A-020-6007AP
3 1B-8.0 inch P.D., 1-1/8 inch Bore 2 6.3 A-030-6007AP
5 1B-9.4 inch P.D., 1-1/8 inch Bore 2 7.6 A-050-6007AP
7-1/2 2B-8.6 inch P.D., 1-3/8 inch Bore 2 12.5 A-100-6007AP
10 2B-8.6 inch P.D., 1-3/8 inch Bore 2 13.5 A-100-6007AP
J PRESSURE ELECTRIC SWITCHES: (For all models)
Lead Switch: Set at approximately
70 psig (490 kPa) cut-in and
90 psig (630 kPa) cut-out 1 0.9 A-100-6010
Lag Switch: Set at approximately
60 psig (420 kPa) cut-in and
80 psig (560kPa) cut-out 1 0.9 A-100-6011
K TANK:
Motor HP Tank Size
3/4 Through 1-1/2 30 gallon 1 134.0 A-015-6030AP
3/4 Through 1-1/2 80 gallon 1 235.0 A-015-6080AP
2 & 3 80 gallon 1 243.0 A-030-6080AP
2 & 3 120 gallon 1 398.0 A-030-6120AP
5 & 7-1/2 120 gallon 1 415.0 A-075-6120AP
5 Through 10 200 gallon 1 677.0 A-100-6200AP
L BELT GUARD:
Motor HP
3/4 Through 1-1/2 2 2.4 A-015-6012AP
2 2 12.5 A-020-6012AP
3 2 12.5 A-030-6012AP
5 2 12.5 A-075-6012AP
7-1/2
(120 Gal) 2 12.5 A-075-6012AP
7-1/2
(200 Gal) 2 12.5 A-075-6022AP
10 2 12.5 A-100-6012AP
M MOTOR:
Motor HP
3/4 (1Ø) 2 32.0 MC301510AV
3/4 (3Ø) 2 25.0 MC301511AV
1 (1Ø) 2 36.0 MC022371AV
1 (3Ø) 2 36.0 MC301512AV
1-1/2 (1Ø) 2 42.0 MC022320AV
1-1/2 (3Ø) 2 44.0 MC301513AV
2 (1Ø) 2 65.0 MC022317AV
2 (3Ø) 2 44.0 MC303300AV
3 2 58.0 MC303301AV
5 2 70.0 MC303303AV
7-1/2 2 73.0 MC303308AV
10 2 124.01 MC303310AV
Replacement Parts List (Continued)
