Scroll Enclosure Air Compressors
Ref.
No. Description
10 HP
SED1007E SED1007EHP
15 HP
SET1507E SET1507EHP
20 HP
SEQ2007E SEQ2007EHP Qty.
1 Air end SL016502AJ SL016511AJ SL016502AJ SL016511AJ SL016502AJ SL016511AJ 2,3,4
2 Motor MC301570AV MC301570AV MC301570AV MC301570AV MC301570AV MC301570AV 2,3,4
3 Motor pulley PU009792AV PU009792AV PU009792AV PU009792AV PU009792AV PU009792AV 2,3,4
4.1 Main circuit board 92971090 * 92972090 * 92973090 * 1
4.2 Display circuit board 92598010 92598010 92598010 92598010 92598010 92598010 1
4.3 Expansion circuit board 92501101 92501101 92501101 92501101 92501101 92501101 1
4.4 Transformer for circuit board 92599010 92599010 92599010 92599010 92599010 92599010 1
5 V-belt BT012001AV BT012001AV BT012001AV BT012001AV BT012001AV BT012001AV 4,6,8
6 Intake fi lter ST073905AV ST073905AV ST073907AV ST073907AV ST073907AV ST073907AV 1
7.1 Intake hose 1 92899060 92899060 92899060 92899060 92803070 92803070 1
7.2 Intake hose 2 92805070 92805070 92805070 92805070 92899060 92899060 1,2,2
7.3 Intake hose 3 N/A N/A N/A N/A 92805070 92805070 1
8 Temperature transducer 02801001 02801001 02801001 02801001 02801001 02801001 2,3,4
9 Pressure sensor 97992133 97992133 97992133 97992133 97992133 97992133 1
10 Check valve CV-157 CV-157 CV-157 CV-157 CV-157 CV-157 2,3,4
11 Safety valve SVB-7B-88 V-215404AV SVB-7B-88 V-215404AV SVB-7B-88 V-215404AV 1
12 Noise fi lter 97992186 97992186 97992186 97992186 97992186 97992186 1
13 Magnetic contactor (for 208, 230V) 97005360 97005360 97005360 97005360 97005360 97005360 2,3,4
Magnetic contactor (for 460V) 92705050 92705050 92705050 92705050 92705050 92705050 2,3,4
14 Terminal 97482010 97482010 97482010 97482010 97482010 97482010 1
15 O-ring IP603200AV IP603200AV IP603200AV IP603200AV IP603200AV IP603200AV 2,3,4
16 Exhaust fan set 97450022 97450022 97450021 97450021 97450021 97450021 1,3,4
17 Control transformer 933445 933445 933445 933445 933445 933445 1
* Consult Authorized Service Center
Replacement Parts List
To Next Page
