22 GB/IE
11
Intensity display ( )
12
Battery symbol ( )
13
Tick Symbol
14
Selection arrow (▼)
15
Power line search (AC)
16
Void search (DEEP)
17
Metal search (METAL)
18
Wooden beam search (STUD)
Technical data
Operating voltage: 9 V (Direct current)
max. 1 mW
Battery type: 6LR61 (9V Block
Battery)
Detector depths:
Wooden beam search
(STUD): max. 19 mm ± 3 mm
Metal search (METAL): max. 30 mm ± 13 mm
Void search (DEEP): max. 38 mm ± 5 mm
Power line search (AC): max. 50 mm (only with
lines which carry
230 V
~
50 Hz)
Scope of delivery
1 Multi-Purpose Detector
1 9 V block battery
1 Pencil
1 Set of operating instructions
