Powerfix Profi PEKW 8 A1 User Manual

Powerfix PEKW 8 A1
English - 11
1. Take the smartphone shell (A) in one hand and the holding mechanism (B) in the
other.
2. Align the 4 lugs on the flat section of
the holding mechanism (B) with the 4
recesses on the smartphone shell (A).
3. Place the 4 lugs on the flat section of
the holding mechanism (B) into the 4
recesses on the smartphone shell (A)
and push the two against one another
such that the 4 lugs engage behind
the recesses and the system catches
into place.
4. Release the two knurled screws (11).
One of the knurled screws (11) can
then be swivelled around 90° so that
the two halves of the grabbers fold
out or can be rotated about the axis
of the other knurled screw (11).
5. Feed the endoscopic camera into the
grabbers until the grabbers fully
encase the thin shaft on the front side
of the handle of the endoscopic
camera.
