1. INSTALLATION
q The installation environment shall be capable of ensuring the user’s safety and the
conditions for a correct operation
q Processor battery charger is exclusively designed to recharge traction batteries and
each unit is assigned to a specific battery.
q Processor battery charger has IP 20 protection degree, therefore it shall be protected
from rain and water sprays. It shall be installed away from easily inflammable materials
and shall not be used as a supporting top. The presence of dust and/or corrosive
environments may damage the components seriously.
q Do not lay any materials which may obstruct the natural cooling air flow
q The rectifier shall be laid on the floor in vertical position. For special requirements it
may also be placed on special raised shelves.
ATTENTION :
VIBRATIONS DURING TRANSPORT COULD CAUSE UNPLEASANT
DRAWBACKS, SO BEFORE STARTING UP THE UNIT, PLEASE CHECK NUTS
AND BOLTS FOR TIGHTNESS.
2. CONNECTION TO THE SINGLE_PHASE LINE
q It is absolutely necessary to plug into a current outlet being proportional to the power of
the installed battery charger
q Make sure also the EARTH cable has been correctly connected.
q The single phase unit comes is pre-set for a 230 - 240 VAC.
3. MAINS VOLTAGE SETTING
q During the installation (or after a displacement) we recommend to check the actual
value of the mains voltage, if found high or low compared with the rated values, may
cause problems due to a higher or lower delivery of current during the charge.
q As a result, check this value and adjust it, if needed, via the ADJUSTING PLUGS
placed in the terminal board on the transformer.
q Such control is to be carried out by qualified staff and/or by service centres.
