Powerline P1 - Page 23

S T E P
8
Selector Rod Top Bolt (34) must be threaded a
minimum of 1/2” into the Selector Rod (31), and
Jam Nut (71) tightened securely against spring lock
washer (63) to ensure proper connection. Check the
Jam Nut (71) once a week to make sure it is tight.
WARNING
Diagram 1
(cable installation)
Diagram 2
(pulley installation)
START HERE
Diagram 1A
23
