58
MAINFRAME PARTS LIST
PART #. QTY. KEY #. DESCRIPTION
A 1 71751015 LOWER MAIN FRAME
B 1 71751018 REAR LEG
C 1 71751017 REAR UPRIGHT
D 1 71751014 UPPER MAIN FRAME
E 1 71751016 REAR UPPER BEAM
F 2 70566104 WEIGHT STACK RISER
G 2 70566008 GUIDE ROD
H 1 71751008 FUNCTION TRAINING ARM
J 1 70566007 FRONT FOOT PLATE
K 1 70566103 LEG EXTENSION ARM
L 1 70566013 SEAT PAD FRAME
M 1 70566012 BACK PAD FRAME
N 1 70566011 BACK PAD ADJUSTMENT
P 1 70566067 STABILIZING LEG
Q 1 71751019 PRESS ARM PIVOT
R 1 70566020 PRESS ARM
S 1 70566021 RIGHT HANDLE
T 1 70566022 LEFT HANDLE
U 1 70566026 PRESS ARM PULLEY COVER
V 1 70566014 UPPER FLOATING PULLEY BRACKET
W 1 70566015 AB CRUNCH PULLEY BRACKET
X 1 70566028 LAT BAR
Y 1 71101040 LOW ROW BAR
AA 2 70566027 BACK/SEAT PAD
AB 2 70544022 FLOATING PULLEY BRACKET
AC 1 71751002 PULLEY BRACKET ASSEMBLY
AD 1 71751006 PULLEY BRACKET
AE 2 71751009 FUNCTIONAL TRAINING ARM PULLEY BRACKET
AF 1 71751001 DOUBLE PULLEY BRACKET
AG 2 71751011 METAL SPACER
