Powerline P2 X - HARDWARE LIST

61
HARDWARE LIST
PART #. QTY. KEY #. DESCRIPTION
84 2 10209010007 BUSHING Φ21.5mm*Φ12mm*14mm
85 1 71751020 "L" PULLEY CABLE PLATE
86 3 71751021 "L" PULLEY CABLE PLATE
87 4 10114000070
10301080810
PRESS ARM BRONZE BUSHING
88 15/20 WEIGHT STACK PLATE 10lbs
92 1 P2 LOGO
93 1 10202140004 PLASTIC BUSHING
94 2 70566072 PULLEY SPACER
95 1 10201010210 HEX HEAD BOLT 12mm*135mm PARTIAL THREAD
96 1 10201150009 NYLON LOCK NUT 12mm
97 1 10201130040 WASHER 12mm
98 5 10201010187 HEX HEAD BOLT 10mm*110mm PARTIAL THREAD
99 2 10201020091 ALLEN HEAD BOLT 10mm*20mm
100 2 10114000007 BRONZE BUSHING
101 4 10201130037 WASHER 10mm
102 2 10201190009 SPRING LOCK WASHER 6mm
103 1 10212010071 SHORT CABLE 700mm
104 1 10212010074
10212010096
10212010094
10212010095
HIGH PULLEY CABLE 4260mm
105 1 BACK PULL PULLEY CABLE 3340mm
106 1 FUNCTION TRAINING ARM PULLEY CABLE 5900mm
107 1 LOW PULLE CABLE 2670mm
