PCCO90X
STEP 5
BE CAREFUL TO ASSEMBLE ALL COMPONENTS
IN THE SEQUENCE THAT THEY ARE PRESENTED.
NOTE:
this step is intended to show you where the pulleys need to be installed
and what hardware you will need to install them. however, you must
install the pulleys the same time you route the cables which can be
found on the next step
5A. left side cable (5170mm, #16) - (L1), install and route
the cable around the pulley and up to (L2). (L2), install
and route the cable around the pulley and then down
to (L3). (L3), install and route the cable around the
pulley and then up to (L4). (L4), install and the route
the cable around the final pulley to complete the left
side cable routing.
5B. right side cable (5170mm, #16) - (R1), install and route
the cable around the pulley and up to (R2). (R2), install
and route the cable around the pulley and then down
to (R3). (R3), install and route the cable around the
pulley and then up to (R4). (R4), install and the route
the cable around the final pulley to complete the right
side cable routing.
5C. attach a snap link followed by a crossover handle (K)
to the left and right side cable at L1 and R1 using a
total of:
2 - (#14) 8mm snap link
20
