NOTE: It is now necessary to turn on the power in order to run the Opener to check for
proper operation and limit settings. Before doing so, ensure that all mounting hardware are
installed and properly tightened, that all electrical connections are per local code requirements, and
that proper wiring practices have been followed. Also, double-check that all ropes have been
removed from the door and that the doorway is clear.
IMPORTANT SAFETY INSTRUCTIONS FOR OWNER
• NEVER let children operate or play with door controls. Keep the Remote Control away from
children.
• ALWAYS keep a moving door in sight and keep people and objects away from the door area
until the door is completely closed. NO ONE SHOULD CROSS THE PATH OF A MOVING
DOOR.
• TEST THE DOOR OPENER’S REVERSING FEATURE (where applicable) MONTHLY. The door
MUST reverse upon contact with a 4” high object on the floor.
• After adjusting the force setting, if equipped with a clutch, or the limit of travel, ALWAYS RETEST
the Opener. Failure to ADJUST THE OPENER PROPERLY may result in SERIOUS INJURY
OR DEATH.
• DO NOT over adjust the force setting (clutch) to compensate for a poorly working door. See
page 14 & 15 for procedure to check the door operation and for proper clutch adjustment.
• KEEP THE GARAGE DOOR PROPERLY BALANCED. (See the door owner's manual.)
• AN IMPROPERLY BALANCED DOOR MAY CAUSE SEVERE INJURY OR DEATH.
• Have a QUALIFIED SERVICE PERSON MAKE REPAIRS TO CABLES, SPRING ASSEMBLIES
AND OTHER HARDWARE.
• SAVE THIS INSTRUCTION MANUAL AND GIVE TO THE END USER.
TO REDUCE THE RISK OF SEVERE INJURY OR
DEATH: READ AND FOLLOW ALL INSTRUCTIONS!
WARNING
FAILURE TO TEST REVERSING SYSTEM COULD
RESULT IN DEATH OR SERIOUS INJURY. TEST
THIS SYSTEM ONCE A MONTH.
WARNING
MOMENTARY CONTACT: Button can be pushed
and then released and door will keep moving or
stop without maintaining pressure on the button.
CONSTANT PRESSURE: Constant pressure is
required on the button in order for continued door
movement. When the button is released the door
will stop and possibly reverse to full open
depending on wiring type.
DOOR EDGE/PHOTOELECTRIC INPUT: The
operator wiring provides for input from an optional
pneumatic or electric door bottom edge or
photoelectric device that will cause a closing door
to stop and may reverse it to open depending on
the wiring type.
WIRING TERMS
13
OPERATION AND ADJUSTMENT INSTRUCTIONS
AVOID ELECTROCUTION:
DO NOT ROUTE LOW VOLTAGE WIRES IN
SAME CONDUIT AS HIGH VOLTAGE WIRES.
FOLLOW ALL LOCAL ELECTRICAL CODES or
THE NATIONAL ELECTRICAL CODE
(NEC).
WARNING
